ENS190 NDIR CO₂ Sensor
The ENS190 is a high-performance, non-dispersive infrared (NDIR) CO₂ sensor designed for precise and reliable carbon dioxide measurement.
At the core of the ENS190 is its patented “M-shaped” long optical path gas chamber, a uniquely engineered design that maximizes the effective optical path within a compact air cavity.
This innovation, combined with a self-developed fully automated high-precision calibration system, ensures exceptional accuracy, consistency, and a wide measurement range.
With its advanced sensing capabilities and robust design, the ENS190 provides a solution for applications demanding high-precision CO₂ monitoring.
It complies with key regulatory standards such as WELL, RESET, California Title 24, and latest ANSI/ASHRAE Addendum d to Standard 62.1-2022.
FEATURES
- Highly accurate CO₂ measurements over extended range
- Compliant with WELL, RESET, California Title 24, and ASHRAE 62.1-2022 Addendum d
- Enlarged air intake aperture
- Automatic High-Precision Calibration
BENEFITS
- Reliable, multi-purpose air quality monitoring
- Meets current regulatory requirements
- Fast response times
- Consistent performance over time without intervention
ENS190 APPLICATIONS
Product |
Part Number |
RoHS compl. |
PB Free |
Package |
Packing QTY |
Shipping Package |
| ENS190 | ENS190 | Y | N | 200 | BOX | |
| ENS190 | ENS190_EK V1 | Y | N | 1 | BOX |
| Accuracy | ±(30ppm + 3% MV) |
| Measurement range | 400 – 10000 ppm CO₂ |
| Alarm output | Yes |
| Communication interface | UART, PWM, RS485 and Modbus |
| Lifetime | >15 years |
| Supply voltage | 4.5 V to 5.5 V |
| Average current consumption | < 15 mA |
| Dimensions | 33 x 20 x 9.6 mm3 |
Please contact Precision Measurement Technologies for technical support, sample requests, pricing and ordering information: call 727-532-6144
